IFB Under Counter Dishwasher Under Counter Dishwasher with 3 Phase Operation

ProTech 613 Plus

Find similar products

2 Minute Wash and Dry
Duoflow Wash Pump
Prodose System

Find the right machine for you needs

Submit

SKU

8903287002588

ENGINEERED FOR SUSTAINABILITY

An automated dosing system that dispenses the exact amount of detergent and rinse-aid needed. Insulated tanks that minimize heat loss and reducing the energy required to maintain optimum wash temperatures. Wash cycles that use the minimum amount of water necessary for a thorough clean. IFB Indutrial dishwashers are engineered to save - detergent power and water.

2 MINUTE WASH AND DRY

Cut wait times to just 2 minutes with IFB industrial dishwashers. Powerful wash pumps, strategically positioned spray arms and high speed wash cycles clean thoroghly, and fast. High-capacity racks accomodate large loads. Dishes come out dry and ready to use. Your service flows uninterrupted even during rush hours.

DUOFLOW WASH PUMPS

Our patented DuoFlow wash pump with one inlet and two outlets - as opposed to traditional pumps with one inlet, one outlet and T or Y shaped flow divertors - ensure that there is no loss of water pressure while delivering water to the wash arms. It delivers 30% more cleaning power compared to the traditional pumps.

360° SPRAY ARMS

Two composite wash arms—one at the top and one at the bottom—with strategically positioned nozzles, spray water from multiple angles for a deep, thorough wash. The lightweight, durable composite material resists corrosion, high temperatures, and chemical damage

DIGITAL CONTROL PANEL

Gives you complete control over the wash process. The display provides clear information on wash cycle progress, temperature and potential errors - for easy monitoring. The intuitive, user - friendly interface simplifies operations, enabling operators to take control with minimal training.

https://s7ap1.scene7.com/is/image/ifb/automated-operations_small-tout

DISHWARE CARE

With the harsh impacts, rough handling, and forceful scrubbing of manual washing gone, your dishware is protected from breakage, scratches and chipping.

PRODOSE SYSTEM

The ProDose system automatically dispenses the exact amount of detergent and rinse aid, elminating waste, reducing costs on chemicals, and manual handling.

VOLTAGE STABILIZER

A voltage stabilizer, built into IFB dishwashers, protects its electronic components from power fluctuations and surges.

Product Information

Product Details

Net Weight (kg) 62

Dimensions (W x D x H - cm) 57.5 x 60 x 82

Rack Size (cm) 50 x 50

Door Opening (W x H - mm) 36.5

Warranty 1 Year

Included Components Detergent Pump, Rinse aid Pump,Warranty card, Power Cable, Installation & User Manual ,Electrical ckt diagram, Installation Lay out, Rat mesh,Water inlet hose, Drain Hose, Glass basket, Dish Basket, Foot leg for leveling

Net Quantity 1 Unit

Performance

Output with 50˚C Water Temperature 50

Maximum Glass Height (cm) 32.5

Plate Length (inch) 18

Aesthetics

General Construction Partial Double Wall

Door Construction Double Wall

Key Features

Partial Double skin construction Yes

Moulded Tank Bottom Yes

Deep Drown, Easy Clean Rack Guides Yes

Prodose Yes

Composite material double filter on pump intake Yes

Wash system with DuoFlo pump Yes

Wash/Rinse with Lower Rotating Arms Yes

Archimedes Drain System Yes

Protect environment improvement system Yes

ProSmart electronic interface Yes

ProSmart LED type electronic interface Yes

No. of standard wash programmes 3

Double skin insulated door Yes

ProSelf - self clean cycle Yes

Drain Pump Optional

Special Cycles ProLong, Prowater, ProGlass, ProEco

Hygienic Wash Yes

Safety Features

ProStrain shock-proof composite material tank filter Yes

Shock Proof Plastic Pump Filter Yes

Technical Sepcifications

Water Consumption (L/Cycle) 2.5

Electric Connection (V/Hz/ph/N) 400/50/3/N

Cycles (secs) 3 (60 - 90 - 180)

Required Electric Power (Kw/Amp) 6.8/16

Required Water Pressure (Bar) 2 - 4

Required Water TDS 40 to 100ppm, Conductivity lower than 300 Micro Siemens

Rinse Temperature (°C) 80

Wash Temperature (°C) 60

Manufacturing,Packaging & Import Details

Importer's Details IFB Industried Ltd

Packer's Details Eurotec S.R.L

Country Of Origin Italy

Learn more about ProTech 613 Plus

<div data-content-type="html" data-appearance="default" data-element="main">The ProTech 613 Plus is 82 cm tall with a door opening of 36.5 cm and deep drawn rack guides. Dishware up to 32.5 cm tall can be cleaned in this under counter dishwasher that operates silently with its dual flow pump and double skin door. It is equipped with Pro-Strain shock-proof composite material tank filter and a double filter on the pump intake. Water and detergent consumption is low, even as wash quality is high and hygienic.</div>
